| MOQ: | 100 square meters |
| Price: | USD 30-100 per square meter |
| Standard Packaging: | Steel pallet |
| Delivery Period: | 30-55 days |
| Payment Method: | T/T, L/C, Western Union, MoneyGram |
| Supply Capacity: | 15000 tons per month |
Prefabricated Steel Structure Factory With Light Weight For Fast Construction
Product Description
Steel structure factory building are among the most affordable buildings to erect. As all of the factory building materials are prefabricated, there will be no delay at the construction site. Each part of the steel frame fix together perfectly, as well as the steel panels as roof and wall cladding. This means it will cost less in labor to install the steel structure factory building, and there’s no excess building material to be wasted.
Steel structure itself is also a very economical building material, and better for the environment. Unlike traditional material, steel is 100% recyclable, which can be re-smelted and used again without loss of any of its properties.
Product Specification
The selection principle of steels for prefab steel factory building:
The principle of steels selection is not only to make the structure safe and reliable and meet the requirements of use, but also to save material and reduce cost. In order to ensure the bearing capacity of the bearing structure and prevent the brittle failure that may occur under certain conditions, the following factors should be considered comprehensively: the importance of the structure, the nature of the load, the connection method, the working environment of the structure, and the thickness of the steels.
| Items | Specification | |
| Main Structure | Column | Q355, Q235 H- steel, Box column is also available |
| Rafter, Beam | Q355, Q235 H- steel | |
| Surface processing options |
1. Epoxy zinc-rich primer + epoxy mica intermediate paint 2. Hot dip galvanization |
|
| Sub Structure | Purlin | Q355B C/Z steel section, galvanization |
| Angle brace | Q235B L- steel | |
| Cross bracing | Q235B round bar, L-steel | |
| Tie bar | Q235B round pipe | |
| Batter brace | Q235B round bar | |
| Roof System | Roof panel options | Q235B Steel |
| Gutter options | Q235B Steel | |
|
Down spout |
Q235B Circular Steel Pipe | |
| Steel flashing and cover | Q235B Round Bar | |
| Wall System | Wall panel options |
Insulated sandwich panel, PU, rock wool, glass fiber, EPS. Two sides is steel sheet. Steel plate Brick wall (provided by client) |
| Door |
Roller door for truck, size customized Sliding door for truck, size customized Access door, steel door, glass door etc |
|
| Window | PVC or Aluminum frame, Fixed, swing, sliding, louver etc | |
| Steel flashing and cover | Steel sheet end cover and corner cover | |
| Accessories and fasteners | Anchor bolts, chemical bolts, high strength bolts, ordinary bolts, self-drilling screws, rivet etc | |
| Other Options | Crane 5T, 6T, 10T, 16T, 30T etc | |
Product Advantages
Advantages of metal frame steel factory:
1. Large span for great strength with light deadweight.
2. Short finishing time and low cost in both material and installation area.
3. Fire proofing and rust proofing.
4. Easy to assemble or disassemble.
5. Environmentally friendly, the metal frame steel factory material can be used again after disassemble.
6. Safe, reliable and has the function of wind resistance and earthquake resistance.
1. The cooperation process begins when a customer sends an inquiry.
2. We then proceed with the design and quotation phase, where our team works closely with the customer to create a tailored solution.
3. Once the project is approved, it moves to our factory for manufacturing and fabrication.
4. After completion, the finished product is shipped to the customer's country for installation. We will provide customers with construction drawings and installation videos, and provide online guidance. If customers have specific needs, we can also send construction personnel to the customer's country for offline installation guidance.
5. Finally, after the installation, the project is complete successfully.
Why choose Qingdao Xinguangzheng?
Xinguangzheng is reckoned as one of the leading prefabricated steel buildings suppliers, we produce a wide range of prefabricated steel buildings excellent quality product with greatest efficiency and exceptional accuracy. Our products conform to the various requirements of the industry from decades, we have upgraded our manufacturing equipment and capabilities of qualified managers, engineers as well as technicians.
The quality and long lasting features of our Xinguangzheng steel structure buildings are commendable and is appreciated by our clients located across various market domains. Our range of products are suited to clients because steel structure buildings we provided satisfy various requirements of clients. We also provide customized solutions as per client specifications that truly help our company to build a strong association with them.
We also occupy a significant share in overseas markets, and our products have been exported to more than 130 countries and regions in the past 25 years. Here are some examples of our exporting countries and buildings.
Customers Visiting
We sincerely invite you to visit our company, we have a total of six factories, a number of workshops, we are confident that after your visit to our cooperation more confidence. Once you have this idea, please let us know immediately, and we will arrange the most professional team to serve you.
FAQ
1. Who you are?
We are a global one-stop manufacturer of steel structure building.
We can offer the service from good design to installation with good quality.
2. How to buy my idea products?
You can provide us your drawing, and we can produce as your drawings.
Or we can design as your requirements if you don’t have a clear plan. We will provide our plans according to the local climatic condition.
3. Do you offer designing service for us?
Yes, we could design full solution drawings as your requirements. By using AutoCAD, PKPM, MTS, 3D3S, Tarch, Tekla Structures (Xsteel) and etc.
4. Can you send engineers to install my structures?
We can provide you with detailed installation drawings and videos for free, and we can also send engineers as installation directors upon request.
5. Do you accept container loading inspection?
Yes, you are welcome to send an inspector any time.
